Details
WHEELS UPGRADED FROM ORIGINAL SPEC:
****************************
DT Swiss XR1700 w/ DT Swiss 350 Wheelset - $500 VALUE ADDED, BUT NOT TO OUR PRICE
****************************
DOMINANT SPEED
Rip through the field with dominance usually reserved for fighter jets and bullet trains. The LES SL’s modern, progressive geometry and innovative carbon science provides the ideal vertical compliance and liveliness to launch you at the starting line and propel you late in the race.
THE FASTEST HARDTAIL WE’VE EVER BUILT
The new LES SL’s geometry features longer reaches and a slacker head angle, leading the pack in a new era of racing hardtails; one that brings a heightened level of capability and aggression to the XC category.
PRODUCT DETAILS
Get everything you need to know about the Les SL.
- Ultra-Featherlight Hollow Core Carbon Frame (800g)
- Best-in-Class Stiffness to Weight Ratios
- Lightweight Integrated Headset
- New-school hardtail racing geometry
- Low Standover Fits Riders 4’10” to 6’ 7”
- Internal Routing with Pivot Cable Port System
- Pivot Dock Tool System Compatible, Under the Top Tube and Bottom Bracket
- Featuring the easy to find UDH rear derailleur hanger for peace of mind when traveling
Size | X-Small | Small | Medium | Large | X-Large |
---|---|---|---|---|---|
Seat Tube Length (C-T) | 35.5 | 39.5 | 42 | 47 | 51 |
Top Tube Length (Eff.) | 56.5 | 59.2 | 62 | 63.8 | 66.8 |
Head Tube Length | 8.5 | 9 | 10 | 11 | 13 |
Head Tube Angle | 68° | 68.5° | 68.5° | 68.5° | 68.5° |
Seat Tube Angle (Eff.) | 75° | 74.5° | 74.5° | 74.5° | 74.5° |
Chain Stay Length | 42.9 | 42.9 | 42.9 | 42.9 | 42.9 |
Bottom Bracket Height | 31 | 31 | 31 | 31 | 31 |
Bottom Bracket Drop | 6.4 | 6.4 | 6.4 | 6.4 | 6.4 |
Standover Height | 62.4 | 63.8 | 65.7 | 67.1 | 67.1 |
Wheelbase | 108.6 | 110.3 | 113.2 | 115 | 118.3 |
Stack | 59.4 | 60.1 | 60.1 | 62 | 63.8 |
Reach | 40 | 42 | 44.5 | 46 | 48.5 |
Size | Height (inches) | Height (cm) |
---|---|---|
X-Small | 4'10" – 5’5” | 147 - 165 |
Small | 5'3" – 5’8” | 160 - 172 |
Medium | 5'5” – 5’11” | 165 - 180 |
Large | 5’10”– 6’1” | 178 - 185 |
X-Large | 6'1" + | 185 + |
Due to supply chain issues, Pivot cannot provide spec information at this time. Please visit our store in person to learn more.
Specs
Frame | LES SL |
---|---|
Fork | Fox Performance Stepcast 32 29", 44mm offset, GRIP - 100mm |
Headset | Pivot Precision Sealed Integrated Cartridge |
Rims/Wheels | NOW UPGRADED IN-STORE WITH - DT Swiss XR1700 w/ DT Swiss 350 hub & 36t Star Ratchet 25mm - 29" 15x110 F/12x148 R / ORIGINAL - DT Swiss X1900 w/ DT Swiss 370 hub, 25mm - 29" 15x110 F/12x148 R |
Tires | Maxxis Ardent Race 29" x 2.2" TR, EXO, 120 TPI Maxxis Ardent Race 29" x 2.2" TR, EXO, 120 TPI |
Crankset | Race Face Ride 32t |
Chain | Shimano CN-M7100 12-Speed |
Rear Derailleur | Shimano XT M8100 SGS 12-Speed |
Rear Cogs | Shimano SLX M7100 10-51t |
Shifters | Shimano SLX M7100 ISPEC EV 12-Speed |
Handlebars | Phoenix Race Low Rise Aluminum - 780mm |
Tape/Grips | Phoenix Factory Lock-On |
Stem | Phoenix Team XC/Trail - 60mm |
Brakes | Shimano SLX M7100 2-piston |
Rotors | Galfer Wave 6-bolt - 160mm Galfer Wave 6-bolt - 160mm |
Saddle | Phoenix WTB Race Volt (Narrow Width) |
Seat Post | Phoenix Race Aluminum |
* Subject to change without notice.
Videos
Part Numbers
Option | UPC | MPN | Store SKU |
---|---|---|---|
Silver Bullet / Medium | 196338164917 | 00LSLV229ASXA--SLBMDSTDHN | 210000003290 |
