Trek Fuel EX 7 Gen 6

Trek Fuel EX 7 Gen 6
  • Color: Penny flake to Dniester Black Fade
  • Color: Deep Dark Blue
$4,399.99
Color:
Size: Select size
Please select options Unavailable
Order now and pick up in-store for free

Details

Fuel EX 7 is a do-anything trail machine evolved to eat up singletrack. Upgraded 150mm front and 140mm rear suspension smooth out rough and technical descents, while a lightweight aluminum frame keeps things lively on the climbs. In-frame storage and adjustable geometry give you all the perks that come with the carbon model, without the price tag. Tubeless wheels, and a reliable SRAM NX Eagle 1x12 drivetrain round-out this build for ultimate trail fun.

It's right for you if...

You're looking for a ride-anything full-suspension trail bike with stepped-up components, like a supple RockShox Gold RL fork that gobbles up rock gardens for fun and flowy descents.
The tech you get

A lightweight alloy full-suspension frame with 150mm RockShox Gold RL fork with DebonAir spring for small bump compliance, and a FOX Performance Float EVOL rear shock. Plus, a 1x12 SRAM NX drivetrain and wide Bontrager wheels with tubeless tires and a dropper post. Adjustable geometry that lets you take control of your setup.
The final word

For the all-mountain rider, Fuel EX 7 takes the cake. Its capable geometry is ready to rally the mountain, and upgraded suspension and drivetrain keep you riding all day.

Why you'll love it:

1. Fuel EX Gen 6 gives you 140/150mm of travel and slack, adjustable geometry for an extra capable ride, plus, in-frame storage on all models — even alloy

2. We expanded our size range to ensure a better fit for all riders, and use the best-fitting wheels for each frame size: XS frames get 27.5? wheels, S frames get to choose between 27.5? or 29?, and sizes M and up get 29? wheels

3. The dropper post lets you lower your saddle on the fly so it's out of the way on descents

4. With the adjustable angle headset (angled cups sold separately) and Mino Link, you can choose from six different geometry configurations

5. In-frame storage offers a spot to stash essential tools and snacks

The shown starting point for geometry is the stock geometry as it arrives. Adjust the geometry for terrain and riding style.

Specs

Frame Alpha Platinum Aluminum, internal storage, angle-adjust headset, Mino Link adjustable geometry, adjustable leverage rate, guided internal routing, magnesium rocker link, 34.9mm seat tube, ISCG 05, 55mm chainline, BSA 73, downtube guard, shuttle guard, ABP, UDH, Boost148, 140mm travel
Fork RockShox 35 Gold RL, DebonAir spring, Motion Control damper, lockout, tapered steerer, 44mm offset, Boost110, 15mm Maxle Stealth, 150mm travel
Headset Integrated cartridge bearing, 1-1/8" top, 1.5" bottom, angle adjust cup compatible
Rear Shock Fox Performance Float EVOL DPS, 2-position damper, 185mm x 55mm
Hubs Front: Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost110, 15mm thru axle / Rear: Bontrager Line Comp 30, Tubeless Ready, Rapid Drive 54, 6-bolt, Boost148, 12mm thru axle
Tires Size: XS , S Bontrager XR5 Team Issue, Tubeless Ready, Inner Strength casing, aramid bead, 60 tpi, 27.5x2.50" / Size: S , M , ML , L , XL , XXL Bontrager XR5 Team Issue, Tubeless Ready, Inner Strength casing, aramid bead, 60 tpi, 29x2.50''
Crankset SRAM X1 Eagle, DUB, 30T steel ring, Boost (55 mm chain line), 170 mm length
Bottom Bracket SRAM DUB MTB Wide, 73mm, BSA threaded
Chain SRAM NX Eagle, 12 speed
Rear Derailleur SRAM NX Eagle
Rear Cogs SRAM PG-1230 Eagle, 11-50, 12 speed
Shifters SRAM NX Eagle, 12 speed
Handlebars Bontrager Rhythm Comp, alloy, 31.8mm, 15mm rise, 750mm width
Tape/Grips Bontrager XR Trail Comp, nylon lock-on
Stem Size: XS , S Bontrager Comp, 31.8mm, 7 degree, 35mm length Size: M , ML , L , XL , XXL Bontrager Comp, 31.8mm, Blendr compatible, 7 degree, 50mm length
Rotors Size: XS , S , M , ML , L , XL , XXL TRP, 6-bolt, 180mm Size: XS , S , M , ML , L , XL , XXL TRP, 6-bolt, 203mm
Pedals Sold separately
Saddle Bontrager Verse Short, stainless steel rails
Seat Post Size: XS , S Bontrager Line Dropper, 100mm travel, MaxFlow, internal routing, 34.9mm, 310mm length Size: M , ML Bontrager Line Dropper, 150mm travel, MaxFlow, internal routing, 34.9mm, 410mm length Size: L , XL , XXL Bontrager Line Dropper, 170mm travel, MaxFlow, internal routing, 34.9mm, 4500mm length
Weight M - 16.08 kg / 35.46 lbs (with TLR sealant, no tubes)

* Subject to change without notice.

Part Numbers

Option UPC MPN Store SKU
Penny flake to Dniester Black Fade / XS (27.5)
Penny flake to Dniester Black Fade / S (27.5)
Penny flake to Dniester Black Fade / S (29)
Penny flake to Dniester Black Fade / M (29) 601479174027 5296676 210000003496
Penny flake to Dniester Black Fade / M/L (29)
Penny flake to Dniester Black Fade / L (29)
Penny flake to Dniester Black Fade / XL (29)
Penny flake to Dniester Black Fade / XXL (29)
Deep Dark Blue / XS (27.5)
Deep Dark Blue / S (27.5)
Deep Dark Blue / S (29)
Deep Dark Blue / M (29)
Deep Dark Blue / M/L (29)
Deep Dark Blue / L (29)
Deep Dark Blue / XL (29)
Deep Dark Blue / XXL (29)
